Coherent AI: Optical R&D Myths Debunked for 2026

The future of AI depends entirely on the speed and efficiency of its plumbing, and that’s why Coherent AI and its optical solutions are where the action is. But there’s a ton of misinformation floating around about where the R&D money is really going in this field. Let’s cut through the hype and see where the actual work is getting done.

Myth 1: AI Datacenter Optics R&D is Primarily About Faster Lasers

A lot of people think optical R&D for AI datacenters is just about making lasers faster or more powerful. That completely misunderstands the complexity. While laser performance matters, the real R&D work at a company like Coherent goes way past the light source. The hard part is figuring out how to modulate, transmit, receive, and integrate that light inside an incredibly dense, power-hungry server rack.

Think about the jump from 400 gigabit per second (Gbps) to 800 Gbps, and now the push to 1.6 terabit per second (Tbps) transceivers, you don’t get there by just swapping in a better laser diode. It takes breakthroughs across the whole optical engine. Coherent, for example, is pouring R&D into modulator technology, shifting from old-school direct modulation to advanced electro-absorption modulated lasers (EMLs) and Mach-Zehnder modulators. These are what let you hit higher data rates by cramming more bits into each symbol using techniques like pulse amplitude modulation (PAM4). This is serious engineering, and it’s why a 2025 LightCounting market analysis predicts that demand for 800G and 1.6T transceivers in AI/ML clusters will rocket up by over 60% annually through 2029. It’s about achieving both speed and clean signal integrity over the short, noisy runs inside a datacenter.

And then there’s the massive R&D job of integrating all these components onto a single chip, creating photonic integrated circuits (PICs). This means developing new material platforms like indium phosphide (InP) and silicon-on-insulator (SOI), because they simply outperform older silicon photonics for this kind of work. InP is especially good for the high-power lasers and efficient modulators Coherent needs for its next-gen products. The real investment is in materials science, wafer fab processes, and advanced packaging, a world away from just tweaking a laser’s output.

Myth 2: Optical R&D is Separated from Electrical Interconnect Design

It’s a common mistake to think optical engineers are in one room and the electrical engineers designing AI accelerators are in another. Nothing could be further from the truth. The line between electrical and optical is getting blurrier every day, especially with co-packaged optics (CPO), where the optical transceivers get mounted directly on the same substrate as the high-bandwidth memory (HBM) and graphics processing units (GPUs) in an AI accelerator package.

The whole point of CPO is to get around the problems with traditional pluggable transceivers, which, for all their flexibility, burn a lot of power and add latency because of the long electrical traces to the main processor. As data rates go up, those traces become a massive bottleneck. Coherent’s CPO research requires its optical and electrical teams to work hand-in-glove on tough problems like thermal management and signal integrity right at the chip level. You can’t just slap an optical interface onto a GPU package. You need entirely new designs and manufacturing to make it survive the brutal heat (often over 85°C) and electrical noise. This kind of integration forces you to completely re-architect how data moves inside an AI server.

At the Optical Fiber Communication Conference (OFC) 2026, we saw prototypes of CPO solutions hitting 3.2 Tbps of aggregate bandwidth per module, hooked directly into next-gen AI silicon. Getting that to work demands true cross-disciplinary expertise. Your teams have to design custom electrical drivers and trans-impedance amplifiers (TIAs) that are perfectly matched for direct coupling with the optics to prevent signal degradation and power waste. This R&D is, by its very nature, interdisciplinary. The idea of separate development tracks is a non-starter.

Myth 3: Scaling AI Optics is Just About Manufacturing More of the Same

There’s a belief that once you finalize a transceiver design, the problem becomes a simple matter of mass production. Manufacturing scale is huge, of course, but the R&D never really stops. Scaling up for AI datacenters creates a whole new set of R&D problems around reliability, power efficiency, and cost reduction at insane volumes. The goal is to make them better, tougher, and cheaper, all at once.

Think about how many optical links you need in a big AI cluster, a single supercomputer can have tens of thousands of transceivers. Making sure every single one of them performs reliably requires some serious statistical process control and predictive analytics on the factory floor. This is why Coherent is investing so much in R&D for automated assembly and testing, developing its own advanced optical alignment systems that use robotics and machine vision to position components with sub-micron accuracy. These are proprietary, in-house systems built to hit very specific yield and throughput numbers.

Power efficiency is another relentless R&D focus. As AI models get bigger, the interconnects can start to eat up a huge chunk of the datacenter’s power budget. Coherent’s teams are constantly looking for ways to lower the watts-per-gigabit figure by designing more efficient laser drivers, lower-power modulators, and better cooling solutions. For instance, the research into using resonant cavity light-emitting diodes (RCLEDs) and vertical-cavity surface-emitting lasers (VCSELs) for short-reach connections is all about finding even more power savings compared to traditional distributed feedback (DFB) lasers. This constant push for efficiency means the R&D never stops, even on products that seem mature.

Myth 4: Optical Networks for AI Are the Same as Enterprise Networks, Just Faster

This myth is surprisingly common. Sure, both enterprise and AI datacenter networks use optical fiber, but that’s where the similarity ends. Their architectures and traffic patterns are completely different, which means they need different R&D. An enterprise network has to deal with all sorts of unpredictable traffic with varying latency needs. An AI training cluster, on the other hand, is all about highly synchronized, east-west traffic, massive, constant data flows between GPUs that demand incredibly low latency and huge bandwidth over short hops.

This is exactly why Coherent’s R&D is focused on specialized optical switching and routing just for AI. Your standard packet-based switch is too slow for many AI workloads. The latency and overhead will kill you. That’s why there’s so much R&D going into optical circuit switching (OCS) and hybrid architectures. OCS creates dedicated, all-optical paths between accelerators, which cuts out electrical conversions and drops latency down to the nanosecond range. OCS isn’t a new idea, but making it work for the dynamic, constantly reconfiguring AI cluster is a whole new ballgame, requiring faster and more reliable optical switches (using MEMS or LCOS) and smart control software that can reroute light on the fly. It’s about building intelligent, dynamic connectivity.

On top of that, the error correction you’d use in an enterprise network is way too slow for AI training. AI interconnects need an extremely low bit error rate (BER) right at the physical layer, so they depend on advanced forward error correction (FEC) that’s built right into the transceiver. Coherent’s R&D involves designing custom FEC algorithms and hardware that can fix errors with almost no latency, protecting data integrity without messing up the tight timing that distributed training depends on. It’s a subtle point, but getting it right requires deep expertise in both optical and digital signal processing (DSP).

Myth 5: All Optical Fiber is the Same for AI Datacenters

A lot of people think any ‘fiber optic’ cable will do for an AI datacenter. That’s not true. The insane bandwidth and short-reach needs of AI clusters are pushing fiber tech to its limits, forcing a lot of specialized R&D. While single-mode fiber (SMF) is still the go-to for longer runs, new types of fiber are being developed for inside the rack and between adjacent racks.

Multicore fiber (MCF) is a perfect example of this R&D. Instead of one core, an MCF cable packs multiple independent cores into a single strand of glass, giving you a way to multiply your bandwidth without needing more physical space, a huge deal when you’re trying to cram interconnects into a dense rack. It’s still early days for MCF in datacenters, but its potential to boost port density and cut down on cable mess is driving serious R&D into how to manufacture it, connect it, and integrate it into a full system. As a proof point, a 2025 paper in the Journal of Lightwave Technology showed an experimental MCF link hitting 100 Tbps over short distances.

Even traditional fiber has issues like PMD and chromatic dispersion that can wreck signal integrity at these high data rates. These problems are smaller over short datacenter runs, but at 1.6 Tbps and beyond, you can’t ignore them. So Coherent’s R&D is also looking at specialized fiber designs and compensation techniques to clean up the signal. This work extends all the way to developing better fiber optic connectors with super low insertion loss and high repeatability which you absolutely need when you’re dealing with the scale and constant changes of AI infrastructure. It really is about the entire physical layer, not just the glass.

The reality of AI datacenter optics demands R&D that goes way beyond simple component swaps. Companies like Coherent are making deep investments in materials science, integrated photonics, co-packaging, and new network designs. If you’re building out AI infrastructure, you have to understand where this R&D is headed. It’s the only way to make smart choices that will future-proof your investment and let you build truly scalable, high-performance AI deployments.
